Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23 1119
15 Parameter reference
15.2 Parameter list
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C02264
C02272
C02273
Parameter | Name:
C02264 | LS_WriteParamList: Empfindlichkeit Sollwertvorsteuerung
Data type: UNSIGNED_8
Index: 22311
d
= 5727
h
From version 12.00.00 onwards: Parameter values (1st value ... 4th value) for optional motor data change-over
Selection list
0Inactive
1 15 bits
2 14 bits
3 13 bits
4 12 bits
5 11 Bit
6 10 Bit
79 Bit
Subcodes Lenze setting Info
C02264/1 0: Inactive LS_WriteParamList
: C653_s1_val1
C02264/2 0: Inactive LS_WriteParamList
: C653_s1_val2
C02264/3 0: Inactive LS_WriteParamList
: C653_s1_val3
C02264/4 0: Inactive LS_WriteParamList
: C653_s1_val4
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C02272 | LS_WriteParamList: Motor phase direction of rotation
Data type: UNSIGNED_8
Index: 22303
d
= 571F
h
From version 12.00.00 onwards: Parameter values (1st value ... 4th value) for optional motor data change-over
Selection list
0not inverted
1inverted
Subcodes Lenze setting Info
C02272/1 0: Not inverted LS_WriteParamList: c905_val1
C02272/2 0: Not inverted LS_WriteParamList
: c905_val2
C02272/3 0: Not inverted LS_WriteParamList
: c905_val3
C02272/4 0: Not inverted LS_WriteParamList: c905_val4
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C02273 | LS_WriteParamList: Speed limitation
Data type: INTEGER_16
Index: 22302
d
= 571E
h
From version 12.00.00 onwards: Parameter values (1st value ... 4th value) for optional motor data change-over
Setting range (min. value | unit | max. value)
0.00 % 175.00
Subcodes Lenze setting Info
C02273/1 120.00 % LS_WriteParamList
: c909_s1_val1
C02273/2 120.00 % LS_WriteParamList
: c909_s1_val2
C02273/3 120.00 % LS_WriteParamList
: c909_s1_val3
C02273/4 120.00 % LS_WriteParamList
: c909_s1_val4
