15 Parameter reference
15.2 Parameter list
1120
Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C02274
C02275
C02276
C02273/5 120.00 % LS_WriteParamList
: c909_s2_val1
C02273/6 120.00 % LS_WriteParamList
: c909_s2_val2
C02273/7 120.00 % LS_WriteParamList
: c909_s2_val3
C02273/8 120.00 % LS_WriteParamList
: c909_s2_val4
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 100
Parameter | Name:
C02273 | LS_WriteParamList: Speed limitation
Data type: INTEGER_16
Index: 22302
d
= 571E
h
Parameter | Name:
C02274 | LS_WriteParamList: Frequency limitation
Data type: UNSIGNED_16
Index: 22301
d
= 571D
h
From version 12.00.00 onwards: Parameter values (1st value ... 4th value) for optional motor data change-over
Setting range (min. value | unit | max. value)
0 Hz 1300
Subcodes Lenze setting Info
C02274/1 1000 Hz LS_WriteParamList
: c910_s1_val1
C02274/2 1000 Hz LS_WriteParamList
: c910_s1_val2
C02274/3 1000 Hz LS_WriteParamList
: c910_s1_val3
C02274/4 1000 Hz LS_WriteParamList
: c910_s1_val4
C02274/5 1000 Hz LS_WriteParamList
: c910_s2_val1
C02274/6 1000 Hz LS_WriteParamList
: c910_s2_val2
C02274/7 1000 Hz LS_WriteParamList
: c910_s2_val3
C02274/8 1000 Hz LS_WriteParamList
: c910_s2_val4
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C02275 | LS_WriteParamList: Motor cable length
Data type: UNSIGNED_16
Index: 22300
d
= 571C
h
From version 12.00.00 onwards: Parameter values (1st value ... 4th value) for optional motor data change-over
Setting range (min. value | unit | max. value)
0.0 m 1000.0
Subcodes Lenze setting Info
C02275/1 5.0 m LS_WriteParamList
: c915_val1
C02275/2 5.0 m LS_WriteParamList
: c915_val2
C02275/3 5.0 m LS_WriteParamList
: c915_val3
C02275/4 5.0 m LS_WriteParamList
: c915_val4
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 10
Parameter | Name:
C02276 | LS_WriteParamList: Motor cable cross-section
Data type: UNSIGNED_16
Index: 22299
d
= 571B
h
From version 12.00.00 onwards: Parameter values (1st value ... 4th value) for optional motor data change-over
Setting range (min. value | unit | max. value)
0.50 mm^2 100.00
Subcodes Lenze setting Info
