Lenze 8400 - Page 1121

Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23 1121
15 Parameter reference
15.2 Parameter list
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C02278
C02279
C02280
C02276/1 6.00 mm^2 LS_WriteParamList
: c916_val1
C02276/2 6.00 mm^2 LS_WriteParamList
: c916_val2
C02276/3 6.00 mm^2 LS_WriteParamList
: c916_val3
C02276/4 6.00 mm^2 LS_WriteParamList
: c916_val4
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 100
Parameter | Name:
C02276 | LS_WriteParamList: Motor cable cross-section
Data type: UNSIGNED_16
Index: 22299
d
= 571B
h
Parameter | Name:
C02278 | LS_WriteParamList: PSM: Maximum motor current field weakening
Data type: UNSIGNED_16
Index: 22297
d
= 5719
h
From version 12.00.00 onwards: Parameter values (1st value ... 4th value) for optional motor data change-over
Setting range (min. value | unit | max. value)
0.00 % 500.00
Subcodes Lenze setting Info
C02278/1 30.00 % LS_WriteParamList
: c938_val1
C02278/2 30.00 % LS_WriteParamList
: c938_val2
C02278/3 30.00 % LS_WriteParamList
: c938_val3
C02278/4 30.00 % LS_WriteParamList
: c938_val4
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 100
Parameter | Name:
C02279 | LS_WriteParamList: Ultimate motor current
Data type: UNSIGNED_16
Index: 22296
d
= 5718
h
From version 12.00.00 onwards: Parameter values (1st value ... 4th value) for optional motor data change-over
Setting range (min. value | unit | max. value)
0.0 A 3000.0
Subcodes Lenze setting Info
C02279/1 3000.0 A LS_WriteParamList
: c939_val1
C02279/2 3000.0 A LS_WriteParamList
: c939_val2
C02279/3 3000.0 A LS_WriteParamList: c939_val3
C02279/4 3000.0 A LS_WriteParamList
: c939_val4
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 10
Parameter | Name:
C02280 | LS_WriteParamList: Max. motor speed
Data type: UNSIGNED_16
Index: 22295
d
= 5717
h
From version 12.00.00 onwards: Parameter values (1st value ... 4th value) for optional motor data change-over
Setting range (min. value | unit | max. value)
50 rpm 65000
Subcodes Lenze setting Info
C02280/1 60000 rpm LS_WriteParamList
: c965_val1
C02280/2 60000 rpm LS_WriteParamList
: c965_val2
C02280/3 60000 rpm LS_WriteParamList
: c965_val3
C02280/4 60000 rpm LS_WriteParamList
: c965_val4
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
