15 Parameter reference
15.2 Parameter list
1128
Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C02301
C02302
C02303
Parameter | Name:
C02301 | LS_WriteParamList: SLPSM: Switching speed
Data type: INTEGER_16
Index: 22274
d
= 5702
h
From version 12.00.00 onwards: Parameter values (1st value ... 4th value) for optional motor data change-over
Setting range (min. value | unit | max. value)
0.00 % 100.00
Subcodes Lenze setting Info
C02301/1 13.00 % LS_WriteParamList
: c996_s1_val1
C02301/2 13.00 % LS_WriteParamList
: c996_s1_val2
C02301/3 13.00 % LS_WriteParamList
: c996_s1_val3
C02301/4 13.00 % LS_WriteParamList
: c996_s1_val4
C02301/5 8.00 % LS_WriteParamList
: c996_s2_val1
C02301/6 8.00 % LS_WriteParamList
: c996_s2_val2
C02301/7 8.00 % LS_WriteParamList
: c996_s2_val3
C02301/8 8.00 % LS_WriteParamList
: c996_s2_val4
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 100
Parameter | Name:
C02302 | LS_WriteParamList: SLPSM: Filter time - rotor position
Data type: INTEGER_16
Index: 22273
d
= 5701
h
From version 12.00.00 onwards: Parameter values (1st value ... 4th value) for optional motor data change-over
Setting range (min. value | unit | max. value)
0.00 % 100.00
Subcodes Lenze setting Info
C02302/1 5.00 % LS_WriteParamList
: c997_val1
C02302/2 5.00 % LS_WriteParamList
: c997_val2
C02302/3 5.00 % LS_WriteParamList
: c997_val3
C02302/4 5.00 % LS_WriteParamList
: c997_val4
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 100
Parameter | Name:
C02303 | LS_WriteParamList: SLPSM: Filter time rotor position
Data type: INTEGER_16
Index: 22272
d
= 5700
h
From version 12.00.00 onwards: Parameter values (1st value ... 4th value) for optional motor data change-over
Setting range (min. value | unit | max. value)
0.5 ms 20.0
Subcodes Lenze setting Info
C02303/1 3.0 ms LS_WriteParamList
: c998_s1_val1
C02303/2 3.0 ms LS_WriteParamList
: c998_s1_val2
C02303/3 3.0 ms LS_WriteParamList
: c998_s1_val3
C02303/4 3.0 ms LS_WriteParamList
: c998_s1_val4
C02303/5 5.0 ms LS_WriteParamList
: c998_s2_val1
C02303/6 5.0 ms LS_WriteParamList
: c998_s2_val2
C02303/7 5.0 ms LS_WriteParamList
: c998_s2_val3
C02303/8 5.0 ms LS_WriteParamList
: c998_s2_val4
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 10
