Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23 1131
15 Parameter reference
15.2 Parameter list
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C02306
C02307
C02311
Parameter | Name:
C02306 | LS_WriteParamList: PSM: Imax Ppp saturation characteristic
Data type: UNSIGNED_16
Index: 22269
d
= 56FD
h
From version 12.00.00 onwards: Parameter values (1st value ... 4th value) for optional motor data change-over
Setting range (min. value | unit | max. value)
0.0 A 3000.0
Subcodes Lenze setting Info
C02306/1 3000.0 A LS_WriteParamList
: c2855_val1
C02306/2 3000.0 A LS_WriteParamList
: c2855_val2
C02306/3 3000.0 A LS_WriteParamList
: c2855_val3
C02306/4 3000.0 A LS_WriteParamList
: c2855_val4
Read access Write access CINH PLC STOP No transfer COM MOT Scaling factor: 10
Parameter | Name:
C02307 | LS_WriteParamList: PSM: Activate Ppp saturation char.
Data type: UNSIGNED_8
Index: 22268
d
= 56FC
h
From version 12.00.00 onwards: Parameter values (1st value ... 4th value) for optional motor data change-over
Selection list
0Off
1On
Subcodes Lenze setting Info
C02307/1 0: Off LS_WriteParamList
: c2859_val1
C02307/2 0: Off LS_WriteParamList
: c2859_val
C02307/3 0: Off LS_WriteParamList
: c2859_val
C02307/4 0: Off LS_WriteParamList
: c2859_val
Read access Write access CINH PLC STOP No transfer COM MOT Scaling factor: 1
Parameter | Name:
C02311 | LS_WriteParamList: PLI without motion: Adaptation of time duration
Data type: INTEGER_8
Index: 22264
d
= 56F8
h
From version 12.00.00 onwards: Parameter values (1st value ... 4th value) for optional motor data change-over
Setting range (min. value | unit | max. value)
-10 10
Subcodes Lenze setting Info
C02311/1 0 LS_WriteParamList
: c2872_s1_val1
C02311/2 0 LS_WriteParamList
: c2872_s1_val2
C02311/3 0 LS_WriteParamList
: c2872_s1_val3
C02311/4 0 LS_WriteParamList
: c2872_s1_val4
Read access Write access CINH PLC STOP No transfer COM MOT Scaling factor: 1
