15 Parameter reference
15.2 Parameter list
1132
Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C02312
C02313
Parameter | Name:
C02312 | LS_WriteParamList: PLI without motion
Data type: UNSIGNED_16
Index: 22263
d
= 56F7
h
From version 12.00.00 onwards: Parameter values (1st value ... 4th value) for optional motor data change-over
Setting range (min. hex value | max. hex value)
0x0000 0xFFFF
Value is bit-coded:
Bit 0 for SLPSM with controller enable
Bit 1 for SC PSM with mains on
Bit 2 for SC PSM with controller enable
Bit 3 for SC PSM once after fault reset
Bit 4 Reserved
Bit 5 Reserved
Bit 6 Reserved
Bit 7 Reserved
Bit 8 Reserved
Bit 9 Reserved
Bit 10 Reserved
Bit 11 Reserved
Bit 12 Reserved
Bit 13 Reserved
Bit 14 Reserved
Bit 15 Reserved
Subcodes Lenze setting Info
C02312/1 0x0001 LS_WriteParamList
: c2874_s1_val1
C02312/2 0x0001 LS_WriteParamList
: c2874_s1_val2
C02312/3 0x0001 LS_WriteParamList
: c2874_s1_val3
C02312/4 0x0001 LS_WriteParamList: c2874_s1_val4
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT
Parameter | Name:
C02313 | LS_WriteParamList: PLI without motion: Adaptation of ident angle
Data type: INTEGER_8
Index: 22262
d
= 56F6
h
From version 12.00.00 onwards: Parameter values (1st value ... 4th value) for optional motor data change-over
Setting range (min. value | unit | max. value)
-100 ° 100
Subcodes Lenze setting Info
C02313/1 0 ° LS_WriteParamList
: c2875_s1_val1
C02313/2 0 ° LS_WriteParamList
: c2875_s1_val2
C02313/3 0 ° LS_WriteParamList
: c2875_s1_val3
C02313/4 0 ° LS_WriteParamList
: c2875_s1_val4
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
