15 Parameter reference
15.2 Parameter list
1138
Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C02611
Subcodes Lenze setting Info
C02610/1 2.000 s Holding brake: ramp time synchr.
• Ramp time for the synchronisation process to
setpoint speed after the brake opening time has
elapsed
Revised behaviour from version 11.00.00:
• The setting made here is only effective if bit 6
"SyncRampe L_NSet_1" in C02582
is set to "0".
• In the Lenze setting of C02582
(Bit 6 = "1"), the ramp
time of the effective acceleration of the ramp
function generator (L_NSet_1
) is used.
Holding brake control
C02610/2 2.000 s MCK: Ramp time synchr. setpoint
• Time for synchronisation ramps between setpoint
jumps occurring through the exceedance of
minimum and maximum speed setpoint limit ranges.
C02610/3 2.000 s MCK: SM stopping ramp
Read access Write access CINH PLC STOP No transfer COM MOT Scaling factor: 1000
Parameter | Name:
C02610 | MCK: Accel./decel. times
Data type: UNSIGNED_32
Index: 21965
d
= 55CD
h
Parameter | Name:
C02611 | MCK: Limitations
Data type: INTEGER_16
Index: 21964
d
= 55CC
h
Speed setpoint limits for the determination of limited validity ranges
Note:
Traversing with setpoints through resulting blocking zones is executed with the ramp set in C02610/2
.
Speed Min/Max
Setting range (min. value | unit | max. value)
0.00 % 199.99
Subcodes Lenze setting Info
C02611/1 199.99 % MCK: Pos. max. speed
• Upper limit of the speed setpoint limitation in
positive direction of rotation.
C02611/2 0.00 % MCK: Pos. min. speed
• Lower limit of the speed setpoint limitation in
positive direction of rotation.
C02611/3 0.00 % MCK: Neg. min. speed
• Lower limit of the speed setpoint limitation in
negative direction of rotation.
C02611/4 199.99 % MCK: Neg. max. speed
• Upper limit of the speed setpoint limitation in
negative direction of rotation.
C02611/5 0.50 % MCK: Max. speed
• From version 12.00.00
• Maximum value for transferring the current speed to
the speed setpoint when the internal operating mode
"StandBy
" is exited.
Read access Write access CINH PLC STOP No transfer COM MOT Scaling factor: 100
