15 Parameter reference
15.2 Parameter list
1140
Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C02811
C02812
C02813
Parameter | Name:
C02811 | TP: Sensor delay
Data type: UNSIGNED_16
Index: 21764
d
= 5504
h
From version 06.00.00
Touch-probe detection
Setting range (min. value | unit | max. value)
0 μs 6999
Subcodes Lenze setting Info
C02811/1 0 μs Reserved
C02811/2 0 μs Reserved
C02811/3 0 μs TPDigIn3: Sensor delay
C02811/4 0 μs TPDigIn4: Sensor delay
C02811/5 0 μs TPDigIn5: Sensor delay
C02811/6 0 μs TPDigIn6: Sensor delay
C02811/7 0 μs TPDigIn7: Sensor delay
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C02812 | TP: Position offset
Data type: INTEGER_32
Index: 21763
d
= 5503
h
From version 06.00.00
Touch-probe detection
Setting range (min. value | unit | max. value)
-214748.3647 units 214748.3647
Subcodes Lenze setting Info
C02812/1 0.0000 units Reserved
C02812/2 0.0000 units Reserved
C02812/3 0.0000 units TPDigIn3: Pos offset
C02812/4 0.0000 units TPDigIn4: Pos offset
C02812/5 0.0000 units TPDigIn5: Pos offset
C02812/6 0.0000 units TPDigIn6: Pos offset
C02812/7 0.0000 units TPDigIn7: Pos offset
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 10000
Parameter | Name:
C02813 | TP: Pos. window start
Data type: INTEGER_32
Index: 21762
d
= 5502
h
From version 06.00.00
Touch-probe detection
Setting range (min. value | unit | max. value)
-214748.3647 units 214748.3647
Subcodes Lenze setting Info
C02813/1 -214748.3647 units TPDigIn3: Window start
C02813/2 -214748.3647 units TPDigIn4: Window start
C02813/3 -214748.3647 units TPDigIn5: Window start
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 10000
