Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23 1141
15 Parameter reference
15.2 Parameter list
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C02814
C02815
C02816
Parameter | Name:
C02814 | TP: Pos. window end
Data type: INTEGER_32
Index: 21761
d
= 5501
h
From version 06.00.00
Touch-probe detection
Setting range (min. value | unit | max. value)
-214748.3647 units 214748.3647
Subcodes Lenze setting Info
C02814/1 214748.3647 units TPDigIn3: Window end
C02814/2 214748.3647 units TPDigIn4: Window end
C02814/3 214748.3647 units TPDigIn5: Window end
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 10000
Parameter | Name:
C02815 | TP: Position source
Data type: UNSIGNED_8
Index: 21760
d
= 5500
h
From version 06.00.00
Touch-probe detection
Selection list
0 Position encoder actual value
1Pos DigIn1/2
Subcodes Lenze setting Info
C02815/1 0: Position encoder actual value Reserved
C02815/2 0: Position encoder actual value Reserved
C02815/3 0: Position encoder actual value TPDigIn3: Position source
C02815/4 0: Position encoder actual value TPDigIn4: Position source
C02815/5 0: Position encoder actual value TPDigIn5: Position source
C02815/6 0: Position encoder actual value TPDigIn6: Position source
C02815/7 0: Position encoder actual value TPDigIn7: Position source
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C02816 | TP: Signal counter
Data type: UNSIGNED_16
Index: 21759
d
= 54FF
h
From version 06.00.00
Touch-probe detection
Display range (min. value | unit | max. value)
0 65535
Subcodes Info
C02816/1 Reserved
C02816/2 Reserved
C02816/3 TPDigIn3: Signal counter
C02816/4 TPDigIn4: Signal counter
C02816/5 TPDigIn5: Signal counter
C02816/6 TPDigIn6: Signal counter
C02816/7 TPDigIn7: Signal counter
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
