17 Function library
17.1 Function blocks | L_DigitalLogic_2
1373
Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
Parameters
Function 4
If the function 4 is selected in C00822
, the output values depend on the truth table parameterised
in C00823/1...24
.
The following table shows which setting may be required in C00823/1...24
to realise the logic
operations NAND, NOR, XOR and XNOR:
Parameters Possible settings Info
C00822
Function selection
0 "0" Constant value "FALSE"
1 "1" Constant value "TRUE"
2AND operation
• bOut2 and bOut3 are available
from version 16.00.00 onwards
3OR operation
• bOut2 and bOut3 are available
from version 16.00.00 onwards
4 bOut = f (truth table)
bOut2 = f (truth table)
bOut3 = f (truth table)
The output value depends on the
truth table parameterised in
C00823/1...24
• bOut2 and bOut3 are available
from version 16.00.00 onwards
C00823/1...24
Truth table for function "4: bOut = f
(truth table)"
• Each of the eight possible input
combinations can be assigned to
the output value FALSE or TRUE.
• For an application example see
the following section.
0FALSE
1TRUE
Input signals Output Parameter setting for logic operation
bIn3 bIn2 bIn1 bOut bOut2 bOut3 NAND NOR XOR XNOR
000C00823/1
C00823/9 C00823/17 =1101
001C00823/2 C00823/10 C00823/18 =1010
010C00823/3
C00823/11 C00823/19 =1010
011C00823/4
C00823/12 C00823/20 =1001
100C00823/5
C00823/13 C00823/21 =1010
101C00823/6
C00823/14 C00823/22 =1001
110C00823/7
C00823/15 C00823/23 =1001
111C00823/8
C00823/16 C00823/24 =0001
bOut bIn1 bIn2 bIn3∧∧=
bOut2 bIn1 bIn2 bIn3∧∧=
bOut3 bIn1 bIn2 bIn3∧∧=
bOut bIn1 bIn2 bIn3∨∨=
bOut2 bIn1 bIn2 bIn3∨∨=
bOut3 bIn1 bIn2 bIn3∨∨=
