15 Parameter reference
15.2 Parameter list
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C00822
C00823
C00821/3 0: FALSE L_DigitalLogic_1
: bOut: bIn3...bIn1=0 1 0
C00821/4 0: FALSE L_DigitalLogic_1
: bOut: bIn3...bIn1=0 1 1
C00821/5 0: FALSE L_DigitalLogic_1
: bOut: bIn3...bIn1=1 0 0
C00821/6 0: FALSE L_DigitalLogic_1
: bOut: bIn3...bIn1=1 0 1
C00821/7 0: FALSE L_DigitalLogic_1
: bOut: bIn3...bIn1=1 1 0
C00821/8 0: FALSE L_DigitalLogic_1
: bOut: bIn3...bIn1=1 1 1
C00821/9 0: FALSE L_DigitalLogic_1
: bOut2: bIn3...bIn1=0 0 0
C00821/10 0: FALSE L_DigitalLogic_1
: bOut2: bIn3...bIn1=0 0 1
C00821/11 0: FALSE L_DigitalLogic_1
: bOut2: bIn3...bIn1=0 1 0
C00821/12 0: FALSE L_DigitalLogic_1
: bOut2: bIn3...bIn1=0 1 1
C00821/13 0: FALSE L_DigitalLogic_1
: bOut2: bIn3...bIn1=1 0 0
C00821/14 0: FALSE L_DigitalLogic_1
: bOut2: bIn3...bIn1=1 0 1
C00821/15 0: FALSE L_DigitalLogic_1
: bOut2: bIn3...bIn1=1 1 0
C00821/16 0: FALSE L_DigitalLogic_1
: bOut2: bIn3...bIn1=1 1 1
C00821/17 0: FALSE L_DigitalLogic_1
: bOut3: bIn3...bIn1=0 0 0
C00821/18 0: FALSE L_DigitalLogic_1
: bOut3: bIn3...bIn1=0 0 1
C00821/19 0: FALSE L_DigitalLogic_1
: bOut3: bIn3...bIn1=0 1 0
C00821/20 0: FALSE L_DigitalLogic_1
: bOut3: bIn3...bIn1=0 1 1
C00821/21 0: FALSE L_DigitalLogic_1
: bOut3: bIn3...bIn1=1 0 0
C00821/22 0: FALSE L_DigitalLogic_1
: bOut3: bIn3...bIn1=1 0 1
C00821/23 0: FALSE L_DigitalLogic_1
: bOut3: bIn3...bIn1=1 1 0
C00821/24 0: FALSE L_DigitalLogic_1
: bOut3: bIn3...bIn1=1 1 1
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C00821 | L_DigitalLogic_1: Truth table
Data type: UNSIGNED_8
Index: 23754
d
= 5CCA
h
Parameter | Name:
C00822 | L_DigitalLogic_2: Function
Data type: UNSIGNED_8
Index: 23753
d
= 5CC9
h
The L_DigitalLogic_2 FB: Selection of the internal logic function
Selection list (Lenze setting printed in bold) Info
0bOut = 0 Constant value "FALSE"
1 bOut = 1 Constant value "TRUE"
2 bOut = bIn1 AND ... bIn3 AND operation
3 bOut = bIn1 OR ... bIn3 OR operation
4 bOut = f (truth table) The truth table parameterised in C00823
is used.
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C00823 | L_DigitalLogic_2: Truth table
Data type: UNSIGNED_8
Index: 23752
d
= 5CC8
h
The L_DigitalLogic_2 FB: Parameterisation of the truth table
Selection list
0False
1True
Subcodes Lenze setting Info
