15 Parameter reference
15.2 Parameter list
974
Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C00820
C00821
Value is bit-coded:
Bit 0 No blocking zone active
Bit 1 Blocking zone 1 active
Bit 2 Blocking zone 2 active
Bit 3 Blocking zone 3 active
Bit 4 Value in blocking zone
Bit 5 Reserved
Bit 6 Reserved
Bit 7 Reserved
Bit 8 Reserved
Bit 9 Reserved
Bit 10 Reserved
Bit 11 Reserved
Bit 12 Reserved
Bit 13 Reserved
Bit 14 Reserved
Bit 15 Reserved
Subcodes Info
C00812/1 L_NLim_1
: Current status
C00812/2 L_NLim_2
: Current status
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT
Parameter | Name:
C00812 | L_NLim: Current status
Data type: UNSIGNED_16
Index: 23763
d
= 5CD3
h
Parameter | Name:
C00820 | L_DigitalLogic_1: Function
Data type: UNSIGNED_8
Index: 23755
d
= 5CCB
h
The L_DigitalLogic_1 FB: Selection of the internal logic function
Selection list (Lenze setting printed in bold) Info
0bOut = 0 Constant value "FALSE"
1 bOut = 1 Constant value "TRUE"
2 bOut = bIn1 AND bIn2 AND bIn3 AND operation
3 bOut = bIn1 OR bIn2 OR bIn3 OR operation
4 bOut = f (truth table) The truth table parameterised in C00821
is used.
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C00821 | L_DigitalLogic_1: Truth table
Data type: UNSIGNED_8
Index: 23754
d
= 5CCA
h
The L_DigitalLogic_1 FB: Parameterisation of the truth table
Selection list
0False
1True
Subcodes Lenze setting Info
C00821/1 0: FALSE L_DigitalLogic_1
: bOut: bIn3...bIn1=0 0 0
C00821/2 0: FALSE L_DigitalLogic_1
: bOut: bIn3...bIn1=0 0 1
