Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23 973
15 Parameter reference
15.2 Parameter list
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C00810
C00811
C00812
Subcodes Lenze setting Info
C00809/1 0.00 % Maximum blocking frequency for zone 1
C00809/2 0.00 % Maximum blocking frequency for zone 2
C00809/3 0.00 % Maximum blocking frequency for zone 3
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 100
Parameter | Name:
C00809 | L_NLim_2: Max.SkipFrq.
Data type: INTEGER_16
Index: 23766
d
= 5CD6
h
Parameter | Name:
C00810 | L_NLim_2: Min.SkipFrq.
Data type: INTEGER_16
Index: 23765
d
= 5CD5
h
FB L_NLim_2: Minimum skip frequencies
Setting range (min. value | unit | max. value)
0.00 % 199.99
Subcodes Lenze setting Info
C00810/1 0.00 % Minimum blocking frequency for zone 1
C00810/2 0.00 % Minimum blocking frequency for zone 2
C00810/3 0.00 % Minimum blocking frequency for zone 3
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 100
Parameter | Name:
C00811 | L_NLim_1: Current output value
Data type: INTEGER_16
Index: 23764
d
= 5CD4
h
From version 11.00.00
Display range (min. value | unit | max. value)
-199.99 % 199.99
Subcodes Info
C00811/1 L_NLim_1: Current output value
C00811/2 L_NLim_2
: Current output value
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 100
Parameter | Name:
C00812 | L_NLim: Current status
Data type: UNSIGNED_16
Index: 23763
d
= 5CD3
h
From version 11.00.00
Display area (min. hex value | max. hex value)
0x0000 0xFFFF
