15 Parameter reference
15.2 Parameter list
972
Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C00806
C00807
C00808
C00809
Parameter | Name:
C00806 | L_MPot_1: Use
Data type: UNSIGNED_8
Index: 23769
d
= 5CD9
h
The L_MPot_1 FB: Use of the motor potentiometer
Selection list (Lenze setting printed in bold) Info
0No The motor potentiometer is not used.
• The analog value applied to the nIn_a input is looped
through without any changes to the nOut_a output.
1 Yes The motor potentiometer is used.
• The analog value applied at the nIn_a input is led via
the motor potentiometer and provided at the nOut_a
output.
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C00807 | L_NLim_1: Max.SkipFrq.
Data type: INTEGER_16
Index: 23768
d
= 5CD8
h
FB L_NLim_1: Maximum blocking frequencies
Setting range (min. value | unit | max. value)
0.00 % 199.99
Subcodes Lenze setting Info
C00807/1 0.00 % Maximum blocking frequency for zone 1
C00807/2 0.00 % Maximum blocking frequency for zone 2
C00807/3 0.00 % Maximum blocking frequency for zone 3
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 100
Parameter | Name:
C00808 | L_NLim_1: Min.SkipFrq.
Data type: INTEGER_16
Index: 23767
d
= 5CD7
h
FB L_NLim_1: Minimum skip frequencies
Setting range (min. value | unit | max. value)
0.00 % 199.99
Subcodes Lenze setting Info
C00808/1 0.00 % Minimum blocking frequency for zone 1
C00808/2 0.00 % Minimum blocking frequency for zone 2
C00808/3 0.00 % Minimum blocking frequency for zone 2
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 100
Parameter | Name:
C00809 | L_NLim_2: Max.SkipFrq.
Data type: INTEGER_16
Index: 23766
d
= 5CD6
h
FB L_NLim_2: Maximum skip frequencies
Setting range (min. value | unit | max. value)
0.00 % 199.99
