15 Parameter reference
15.2 Parameter list
976
Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C00824
C00825
C00823/1 0: FALSE L_DigitalLogic_2
: bOut: bIn3...bIn1=0 0 0
C00823/2 0: FALSE L_DigitalLogic_2
: bOut: bIn3...bIn1=0 0 1
C00823/3 0: FALSE L_DigitalLogic_2
: bOut: bIn3...bIn1=0 1 0
C00823/4 0: FALSE L_DigitalLogic_2
: bOut: bIn3...bIn1=0 1 1
C00823/5 0: FALSE L_DigitalLogic_2
: bOut: bIn3...bIn1=1 0 0
C00823/6 0: FALSE L_DigitalLogic_2
: bOut: bIn3...bIn1=1 0 1
C00823/7 0: FALSE L_DigitalLogic_2
: bOut: bIn3...bIn1=1 1 0
C00823/8 0: FALSE L_DigitalLogic_2
: bOut: bIn3...bIn1=1 1 1
C00823/9 0: FALSE L_DigitalLogic_2
: bOut2: bIn3...bIn1=0 0 0
C00823/10 0: FALSE L_DigitalLogic_2
: bOut2: bIn3...bIn1=0 0 1
C00823/11 0: FALSE L_DigitalLogic_2
: bOut2: bIn3...bIn1=0 1 0
C00823/12 0: FALSE L_DigitalLogic_2
: bOut2: bIn3...bIn1=0 1 1
C00823/13 0: FALSE L_DigitalLogic_2
: bOut2: bIn3...bIn1=1 0 0
C00823/14 0: FALSE L_DigitalLogic_2
: bOut2: bIn3...bIn1=1 0 1
C00823/15 0: FALSE L_DigitalLogic_2
: bOut2: bIn3...bIn1=1 1 0
C00823/16 0: FALSE L_DigitalLogic_2
: bOut2: bIn3...bIn1=1 1 1
C00823/17 0: FALSE L_DigitalLogic_2
: bOut3: bIn3...bIn1=0 0 0
C00823/18 0: FALSE L_DigitalLogic_2
: bOut3: bIn3...bIn1=0 0 1
C00823/19 0: FALSE L_DigitalLogic_2
: bOut3: bIn3...bIn1=0 1 0
C00823/20 0: FALSE L_DigitalLogic_2
: bOut3: bIn3...bIn1=0 1 1
C00823/21 0: FALSE L_DigitalLogic_2
: bOut3: bIn3...bIn1=1 0 0
C00823/22 0: FALSE L_DigitalLogic_2
: bOut3: bIn3...bIn1=1 0 1
C00823/23 0: FALSE L_DigitalLogic_2
: bOut3: bIn3...bIn1=1 1 0
C00823/24 0: FALSE L_DigitalLogic_2
: bOut3: bIn3...bIn1=1 1 1
Read access Write access CINH PLC STOP No transfer COM MOT Scaling factor: 1
Parameter | Name:
C00823 | L_DigitalLogic_2: Truth table
Data type: UNSIGNED_8
Index: 23752
d
= 5CC8
h
Parameter | Name:
C00824 | L_DigitalLogic5_1: Function
Data type: UNSIGNED_8
Index: 23751
d
= 5CC7
h
FB L_DigitalLogic5_1: Selection of the interna logic operation
Selection list (Lenze setting printed in bold) Info
0bOut = 0
1bOut = 1
2 bOut = f (truth table) The truth table parameterised in C00825
is used.
Read access Write access CINH PLC STOP No transfer COM MOT Scaling factor: 1
Parameter | Name:
C00825 | L_DigitalLogic5_1: Truth table
Data type: UNSIGNED_8
Index: 23750
d
= 5CC6
h
FB L_DigitalLogic5_1: Parameter setting of the truth table
Selection list
0False
1True
Subcodes Lenze setting Info
