Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23 977
15 Parameter reference
15.2 Parameter list
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C00826
C00825/1 0: FALSE L_DigitalLogic5_1
: bIn5...bIn1=0 0 0 0 0
C00825/2 0: FALSE L_DigitalLogic5_1
: bIn5...bIn1=0 0 0 0 1
C00825/3 0: FALSE L_DigitalLogic5_1
: bIn5...bIn1=0 0 0 1 0
C00825/4 0: FALSE L_DigitalLogic5_1
: bIn5...bIn1=0 0 0 1 1
C00825/5 0: FALSE L_DigitalLogic5_1
: bIn5...bIn1=0 0 1 0 0
C00825/6 0: FALSE L_DigitalLogic5_1
: bIn5...bIn1=0 0 1 0 1
C00825/7 0: FALSE L_DigitalLogic5_1
: bIn5...bIn1=0 0 1 1 0
C00825/8 0: FALSE L_DigitalLogic5_1
: bIn5...bIn1=0 0 1 1 1
C00825/9 0: FALSE L_DigitalLogic5_1
: bIn5...bIn1=0 1 0 0 0
C00825/10 0: FALSE L_DigitalLogic5_1
: bIn5...bIn1=0 1 0 0 1
C00825/11 0: FALSE L_DigitalLogic5_1
: bIn5...bIn1=0 1 0 1 0
C00825/12 0: FALSE L_DigitalLogic5_1
: bIn5...bIn1=0 1 0 1 1
C00825/13 0: FALSE L_DigitalLogic5_1
: bIn5...bIn1=0 1 1 0 0
C00825/14 0: FALSE L_DigitalLogic5_1
: bIn5...bIn1=0 1 1 0 1
C00825/15 0: FALSE L_DigitalLogic5_1
: bIn5...bIn1=0 1 1 1 0
C00825/16 0: FALSE L_DigitalLogic5_1
: bIn5...bIn1=0 1 1 1 1
C00825/17 0: FALSE L_DigitalLogic5_1
: bIn5...bIn1=1 0 0 0 0
C00825/18 0: FALSE L_DigitalLogic5_1
: bIn5...bIn1=1 0 0 0 1
C00825/19 0: FALSE L_DigitalLogic5_1
: bIn5...bIn1=1 0 0 1 0
C00825/20 0: FALSE L_DigitalLogic5_1
: bIn5...bIn1=1 0 0 1 1
C00825/21 0: FALSE L_DigitalLogic5_1
: bIn5...bIn1=1 0 1 0 0
C00825/22 0: FALSE L_DigitalLogic5_1
: bIn5...bIn1=1 0 1 0 1
C00825/23 0: FALSE L_DigitalLogic5_1
: bIn5...bIn1=1 0 1 1 0
C00825/24 0: FALSE L_DigitalLogic5_1
: bIn5...bIn1=1 0 1 1 1
C00825/25 0: FALSE L_DigitalLogic5_1
: bIn5...bIn1=1 1 0 0 0
C00825/26 0: FALSE L_DigitalLogic5_1: bIn5...bIn1=1 1 0 0 1
C00825/27 0: FALSE L_DigitalLogic5_1
: bIn5...bIn1=1 1 0 1 0
C00825/28 0: FALSE L_DigitalLogic5_1: bIn5...bIn1=1 1 0 1 1
C00825/29 0: FALSE L_DigitalLogic5_1
: bIn5...bIn1=1 1 1 0 0
C00825/30 0: FALSE L_DigitalLogic5_1
: bIn5...bIn1=1 1 1 0 1
C00825/31 0: FALSE L_DigitalLogic5_1: bIn5...bIn1=1 1 1 1 0
C00825/32 0: FALSE L_DigitalLogic5_1
: bIn5...bIn1=1 1 1 1 1
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C00825 | L_DigitalLogic5_1: Truth table
Data type: UNSIGNED_8
Index: 23750
d
= 5CC6
h
Parameter | Name:
C00826 | L_DigitalLogic5_2: Function
Data type: UNSIGNED_8
Index: 23749
d
= 5CC5
h
FB L_DigitalLogic5_2: Selection of the interna logic operation
Selection list (Lenze setting printed in bold) Info
0bOut = 0
1bOut = 1
2 bOut = f (truth table) The truth table parameterised in C00827
is used.
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
