17.2 System blocks | LS_PulseGenerator
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
Parameters
 Note!
The real length of the low or high level at the bSquareWave output is always 1 ms higher
than set in C00400/1
or C00400/2. If "0 ms" is set, a level with a length of 1 ms is created
length, for instance, and if "1000 ms" is set, a level with a length of 1001 ms is created.
Parameters Possible settings Info
C00400/1
0 ms 60000 Length of the low level (break) + 1 ms
• For output bSquareWave
• Lenze setting: 1000 ms
C00400/2
0 ms 60000 Length of the high level + 1 ms
• For output bSquareWave
• Lenze setting: 1000 ms
C00400/3
(from version 06.00.00)
0 ms 60000 Delay of the status bFirstCycleDone
• Lenze setting: 100 ms
