17 Function library
17.2 System blocks | LS_RetainData
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
Outputs
Parameters
Designator
Data type
Value/meaning
wOut1 ... wOut4
WORD
Output of the input or retain values, depending on the bSetRetain input
dnOut1 ... dnOut4
DINT
bOut1 ... bOut4
BOOL
Parameters Possible settings Info
C01130/1...4
Setting is bit coded: Subcodes 1 ... 3: Selection 1 ... 3
• Select which input values are to
be stored in the retain memory
when setting the respective
bSetRetain-input to TRUE.
• Lenze setting: 0x0000
Subcode 4: Parameter selection
• Select which parameter values are
to be stored in the retain memory
when setting bLoadParams to
TRUE.
• Lenze setting: 0x0000
Subcodes 1 ... 3: Subcode 4:
Bit 0 wIn1 C01131/1
Bit 1 wIn2 C01131/2
Bit 2 wIn3 C01131/3
Bit 3 wIn4 C01131/4
Bit 4 dnIn1 C01132/1
Bit 5 dnIn2 C01132/2
Bit 6 dnIn3 C01132/3
Bit 7 dnIn4 C01132/4
Bit 8 bIn1 C01133/1
Bit 9 bIn2 C01133/2
Bit 10 bIn3 C01133/3
Bit 11 bIn4 C01133/4
Bit 12 Reserved
Bit 13
Bit 14
Bit 15
C01131/1...4
0 65536 Parameter value for retain memory
(outputs wOut1 ... wOut4)
•Lenze setting: 0
C01132/1...4
-2147483647 2147483647 Parameter values for retain memory
(outputs dnOut1 ... dnOut4)
•Lenze setting: 0
C01133/1...4
Parameter values for retain memory
(outputs bOut1 ... bOut4)
• Lenze setting: 0: FALSE
0FALSE
1TRUE
