Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23 395
7 Technology applications
7.2 TA "Actuating drive speed"
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
Bit 14 SetFail 1 ≡ Set error (trip set)
Bit 15 SetSpeedCcw 0 ≡ Direction of rotation to the right (Cw)
1 ≡ Direction of rotation to the left (Ccw)
Output words Name Assignment
Word 1 DriveControlStatus Status word
• For bit assignment see the table below.
Word 2 MotorSpeedAct Actual speed value
• Scaling: 16384 ≡ 100 % reference speed (C00011
)
Word 3 MotorSpeedSet Resulting overall setpoint
• Scaling: 16384 ≡ 100 % reference speed (C00011
)
Word 4 - Not preconfigured
Words 5 ... 16 - Not preconfigured
• Only available in control mode "40: MCI".
Status word Name Status
Bit 0 FreeStatusBit0 Free status bit 0 (not assigned, freely assignable)
Bit 1 PowerDisabled 1 ≡ Inverter control inhibited (pulse inhibit is active)
Bit 2 FreeStatusBit2 Free status bit 2 (not assigned, freely assignable)
Bit 3 FreeStatusBit3 Free status bit 3 (not assigned, freely assignable)
Bit 4 FreeStatusBit4 Free status bit 4 (not assigned, freely assignable)
Bit 5 FreeStatusBit5 Free status bit 5 (not assigned, freely assignable)
Bit 6 ActSpeedIsZero During open-loop operation:
1 ≡ Speed setpoint < Comparison value (C00024
)
During closed-loop operation:
1 ≡ Actual speed value < Comparison value (C00024
)
Bit 7 ControllerInhibit 1 ≡ Inverter is inhibited (controller inhibit is active)
Bit 8 StatusCodeBit0 Bit coded display of the active device status
Device state machine and device states
(see table [4-1])
Bit 9 StatusCodeBit1
Bit 10 StatusCodeBit2
Bit 11 StatusCodeBit3
Bit 12 Warning 1 ≡ a warning is indicated
Bit 13 Trouble 1 ≡ Inverter is in the "Trouble
" device status
•E.g. if an overvoltage has occurred.
Bit 14 FreeStatusBit14 Free status bit 14 (not assigned, freely assignable)
Bit 15 FreeStatusBit15 Free status bit 15 (not assigned, freely assignable)
