Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23 821
15 Parameter reference
15.2 Parameter list
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C00023
C00024
C00025
C00026
Parameter | Name:
C00023 | Imax in generator mode
Data type: INTEGER_16
Index: 24552
d
= 5FE8
h
Maximum current in generator mode for all motor control modes
•100% ≡ Imax in motor mode (C00022
)
Setting range (min. value | unit | max. value) Lenze setting
0.00 % 100.00 100.00 %
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 100
Parameter | Name:
C00024 | LS_DriveInterface: bNActCompare
Data type: INTEGER_16
Index: 24551
d
= 5FE7
h
Threshold for the actual speed comparison
• This parameter serves to set a threshold that is compared with the actual speed value.
• If the value falls below this threshold, the bNactCompare output sets the LS_DriveInterface
system block to
TRUE.
• Switching hysteresis = +1 %
CAUTION:
There are errors in the evaluation if the sum of 199.98 % is exceeded in case of the set value combinations.
Setting range (min. value | unit | max. value) Lenze setting
0.00 % 199.99 0.00 %
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 100
Parameter | Name:
C00025 | LS_DriveInterface: bNActHysterese
Data type: INTEGER_16
Index: 24550
d
= 5FE6
h
From version 16.00.00
Selection of the switching hysteresis for the actual speed value comparison in C00024
.
CAUTION:
There are errors in the evaluation if the sum of 199.98 % is exceeded in case of the set value combinations.
Setting range (min. value | unit | max. value)
0.00 % 199.99
Subcodes Lenze setting Info
C00025/1 1.00 % LS_DriveInterface
: bNActHysterese
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 100
Parameter | Name:
C00026 | AINx: Offset
Data type: INTEGER_16
Index: 24549
d
= 5FE5
h
Offset for analog inputs
Analog terminals
Setting range (min. value | unit | max. value)
-199.99 % 199.99
Subcodes Lenze setting Info
C00026/1 0.00 % AIN1: Offset
C00026/2 0.00 % AIN2: Offset
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 100
