15 Parameter reference
15.2 Parameter list
820
Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C00020
C00021
C00022
Parameter | Name:
C00020 | AIN2: Characteristic
Data type: INTEGER_16
Index: 24555
d
= 5FEB
h
From version 04.00.00
Analog terminals
: Signal adaptation via characteristic
Setting range (min. value | unit | max. value)
0.00 % 199.99
Subcodes Lenze setting Info
C00020/1 0.00 % AIN2: (+y0) = min
C00020/2 0.00 % AIN2: (+x0) = Dead band
C00020/3 0.00 % AIN2: (-y0) = (-min)
C00020/4 0.00 % AIN2: (-x0) = (-Dead band)
C00020/5 100.00 % AIN2: (+ymax)
C00020/6 100.00 % AIN2: (+xmax)
C00020/7 100.00 % AIN2: (-ymax)
C00020/8 100.00 % AIN2: (-xmax)
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 100
Parameter | Name:
C00021 | Slip comp.
Data type: INTEGER_16
Index: 24554
d
= 5FEA
h
Slip compensation for V/f characteristic control (VFCplus) and sensorless vector control (SLVC)
• A higher slip compensation results in a higher increase in frequency and voltage when the machine is under load.
• After the motor to be used has been selected from the motor catalogue, the suitable value can be entered
automatically. An automatic detection via the motor parameter identification is possible as well.
Motor control (MCTRL)
: Optimising the operational performance by slip compensation
Setting range (min. value | unit | max. value) Lenze setting
-100.00 % 100.00 power-related (see table
)
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 100
Parameter | Name:
C00022 | Imax in motor mode
Data type: UNSIGNED_16
Index: 24553
d
= 5FE9
h
Maximum current in motor mode for all motor control modes
Note:
The parameter has a value range depending on the device power. The device automatically limits the entered value
to the corresponding value range.
Setting range (min. value | unit | max. value) Lenze setting
0.00 A 655.35 power-related (see table
)
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 100
