9 Diagnostics & error management
9.9 Error messages of the operating system
648
Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
Error type
The error type gives information about the behaviour/response of the inverter to the error. The error
type for some device errors can also be parameterised.
Error subject area
The error subject area indicates the internal "function unit" of the inverter in which the error has
occurred:
Error ID
Bit 29 Bit 28 Bit 27 Bit 26 Meaning
0 0 0 0 0: No Response
00011: Fault
00102: Trouble
00113: TroubleQSP
01004: WarningLocked
01015: Warning
01106: Information
Error subject area Assigned errors Remedy possible by
user?
No. Name
111 Supply voltage Errors that occur in connection with the supply voltage of the device. Yes
119 Temperature Errors that occur for temperature reasons. Yes
123 Motor management / encoder Errors that occur within the motor control or encoder evaluation. Yes
125 Analog I/O integrated Errors that occur in connection with the analog inputs and outputs. Yes
127 Extension module slot 1 Errors that are reported by the extension module, and
communication errors to the plugged-in extension module.
Yes if it is a fieldbus error.
131 CAN integrated (general) Errors related to general CAN functions. Yes
135 CAN process data object (PDO) Errors that are explicitly only related to the CAN-PDO (process data
objects).
Yes
140 Device configuration Errors that occur due to incompatibilities of the plugged-in individual
components (fieldbus module, safety module, et al.).
Yes if the error relates to a
module plugged-in by the
user.
144 Parameter set Errors that occur in connection with the parameter set or the
parameter set memory (memory module).
Yes if the error relates to a
missing or incompatible
memory module.
145 Device firmware (internal error) Internal error of the device firmware. No
184 MotionControlKernel Errors that occur within the MotionControl basic functions (e.g.
profile generation, brake control, positioning).
Yes
400 Defective device hardware Errors that occur due to defective device hardware. No
444 Fieldbus Errors that occur in connection with fieldbus communication. Yes
980
...
983
User error 1
...
User error 4
Errors generated by the user (by the application) via the
LS_SetError_1
system block.
Yes
984
...
987
User error 5
...
User error 8
Errors generated by the user (by the application) via the
LS_SetError_2 system block.
Yes
