11 System bus "CAN on board"
11.9 Parameter data transfer
746
Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
Telegram 2 to the drive: Request of the 1st data block
Response telegram 2 from the drive: Transmission of the 1st data block
Identifier User data
1st byte 2nd byte 3rd byte 4th byte 5th byte 6. byte 7th byte 8th byte
Command Data 1 Data 2 Data 3 Data 4 Data 5 Data 6 Data 7
0x060C 0x60 0x00 0x00 0x00 0x00 0x00 0x00 0x00
Explanations on the telegram to the drive
Command = 0x60 = "Read segment request" (request: read data block)
• Bit 4 = 0 (toggle bit)
Influence of the toggle bit on the request command
The single blocks are toggled one after another, i.e. first the request is made with the "0x60"
command (= 0b0110*0000), then with the "0x70" command (= 0b0111*0000), and then again
with the "0x60" command, etc.
* Toggle bit
Identifier User data
1st byte 2nd byte 3rd byte 4th byte 5th byte 6. byte 7th byte 8th byte
Command Data 1 Data 2 Data 3 Data 4 Data 5 Data 6 Data 7
0x058C 0x00 0x30 0x31 0x2E 0x30 0x30 0x2E 0x30
0
asc
1
asc
.
asc
0
asc
0
asc
.
asc
0
asc
Explanations on the telegram to the drive
Command = 0x00 = 0b00000000
• Bit 4 = 0 (toggle bit)
Influence of the toggle bit on the transmission command
• The 1st response of the inverter in the command byte is "0b0000*0000" if bytes 2 ... 8 are
completely filled with data and other telegrams are following.
• The 2nd response of the inverter in the command byte is "0b00011*0000" if bytes 2 ... 8 are
completely filled with data and other telegrams are following.
* Toggle bit
Data 1 ... 7 = "01.00.0" (ASCII representation)
