Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23 823
15 Parameter reference
15.2 Parameter list
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C00034
C00036
C00039
Display range (min. value | unit | max. value)
-199.99 % 199.99
Subcodes Info
C00033/1 AIN1: Output value
C00033/2 AIN2: Output value
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 100
Parameter | Name:
C00033 | AINx: Output value
Data type: INTEGER_16
Index: 24542
d
= 5FDE
h
Parameter | Name:
C00034 | AINx: Configuration
Data type: UNSIGNED_8
Index: 24541
d
= 5FDD
h
Configuration of the analog inputs for current or voltage measurement
Analog terminals
Selection list Info
0 -10V..+10V Input signal is the voltage signal -10 V ... +10 V
• -10 V ... +10 V ≡ -100 % ... +100 %
1 0mA..20mA Input signal is the current signal 0 mA ... 20 mA
•0mA...20mA ≡ 0%...+100%
2 4mA..20mA Input signal is the current signal 4 mA ... 20 mA
•4mA...20mA ≡ 0%...+100%
• The current loop is monitored for open circuit
(I < 4 mA) by the device.
Subcodes Lenze setting Info
C00034/1 0: -10V..+10V AIN1: Config.
C00034/2 0: -10V..+10V AIN2: Config.
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C00036 | DC braking: Current
Data type: INTEGER_16
Index: 24539
d
= 5FDB
h
Braking current in [%] based on rated device current (C00098)
•100% ≡ C00098
DC-injection braking
Setting range (min. value | unit | max. value) Lenze setting
0.00 % 200.00 50.00 %
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 100
Parameter | Name:
C00039 | Fixed setpoint x (L_NSet_1 n-Fix)
Data type: INTEGER_16
Index: 24536
d
= 5FD8
h
The L_NSet_1 FB: Fixed speed setpoints (JOG values) for the setpoint generator
•100% ≡ C00011
Setting range (min. value | unit | max. value)
-199.99 % 199.99
Subcodes Lenze setting Info
C00039/1 40.00 % Fixed setpoint 1
C00039/2 60.00 % Fixed setpoint 2
C00039/3 80.00 % Fixed setpoint 3
