15 Parameter reference
15.2 Parameter list
850
Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C00164
84 MCI word2 input bit13
85 MCI word2 input bit14
86 MCI word2 input bit15
87 Position controller: Limit
88 Speed controller: Limit
89 Speed setpoint: Limit
90 Torque setpoint: Limit
91 Current setpoint: Limit
92 DC injection brake active
93 Quick stop active
94 Pulse inhibit active
95 Controller inhibit active
96 Safe status active
97 Direction of rotation ccw
98 Actual speed = 0
99 L_Or_1: Out
100 L_DFlipFlop_1: Out
101 L_DigitalDelay_1: Out
102 L_Compare_1: Out
103 L_Compare_2: Out
104 L_NSet_1: Setpoint reached
105 L_DigitalLogic_1: Out
106 L_SignalMonitor_b: Out1
107 L_SignalMonitor_b: Out2
108 L_SignalMonitor_b: Out3
109 L_SignalMonitor_b: Out4
110 L_PCTRL_1: act=set
Subcodes Lenze setting Info
C00163/1 0: No signal Logbook - binary element 1
C00163/2 0: No signal Logbook - binary element 2
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C00163 | Logbook - binary elements
Data type: UNSIGNED_16
Index: 24412
d
= 5F5C
h
Parameter | Name:
C00164 | Logbook - analog elements
Data type: UNSIGNED_16
Index: 24411
d
= 5F5B
h
Selection of an analog signal to be logged in the logbook
Selection list Info
0No signal
1AIN1
2CAN1 control word
3CAN1 input word 2
4CAN1 input word 3
5CAN1 input word 4
6CAN2 input word 1
