Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23 869
15 Parameter reference
15.2 Parameter list
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C00276
C00280
C00290
C00291
C00295
C00296
C00297
Parameter | Name:
C00276 | SC: Max. output voltage
Data type: UNSIGNED_8
Index: 24299
d
= 5EEB
h
From version 02.00.00
Maximum output voltage at servo control (SC
)
• Regarding the current DC-bus voltage.
Setting range (min. value | unit | max. value) Lenze setting
80 % 99 95 %
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C00280 | SC: Filter time const. DC detection
Data type: UNSIGNED_16
Index: 24295
d
= 5EE7
h
Filter time constant for DC-bus voltage filtering
• The filter time constant is e.g. used for field weakening control at servo control (SC
).
Setting range (min. value | unit | max. value) Lenze setting
1 ms 1000 25 ms
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C00290 | RCOM error counter
Data type: UNSIGNED_16
Index: 24285
d
= 5EDD
h
This code is for device-internal use only and must not be written to by the user!
Parameter | Name:
C00291 | Error type RCOM
Data type: UNSIGNED_8
Index: 24284
d
= 5EDC
h
This code is for device-internal use only and must not be written to by the user!
Parameter | Name:
C00295 | savezycle memory modul
Data type: INTEGER_32
Index: 24280
d
= 5ED8
h
This code is for device-internal use only and must not be written to by the user!
Parameter | Name:
C00296 | ICOM error number
Data type: UNSIGNED_16
Index: 24279
d
= 5ED7
h
This code is for device-internal use only and must not be written to by the user!
Parameter | Name:
C00297 | Counter Receive Error Isr
Data type: UNSIGNED_8
Index: 24278
d
= 5ED6
h
This code is for device-internal use only and must not be written to by the user!
