Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23 877
15 Parameter reference
15.2 Parameter list
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C00345
C00347
C00344/9 0 LP_CanOut3
:wOut1 DiscVal
C00344/10 0 LP_CanOut3
:wOut2 DiscVal
C00344/11 0 LP_CanOut3
:wOut3 DiscVal
C00344/12 0 LP_CanOut3
:wOut4 DiscVal
C00344/13 0 LP_CanOut4
:wOut1 DiscVal
• From version 15.00.00
C00344/14 0 LP_CanOut4
:wOut2 DiscVal
• From version 15.00.00
C00344/15 0 LP_CanOut4
:wOut3 DiscVal
• From version 15.00.00
C00344/16 0 LP_CanOut4
:wOut4 DiscVal
• From version 15.00.00
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C00344 | LP_CanOut decoupling value
Data type: UNSIGNED_16
Index: 24231
d
= 5EA7
h
Parameter | Name:
C00345 | CAN error status
Data type: UNSIGNED_8
Index: 24230
d
= 5EA6
h
"CAN on board" system bus
Selection list (read only)
0 No Error
1 Warning ErrActive
2 Warning ErrPassive
3 Bus off
4 Reserved
5 Reserved
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C00347 | CAN status HeartBeat producer
Data type: UNSIGNED_8
Index: 24228
d
= 5EA4
h
Heartbeat protocol
Selection list
0 Boot-up
4 Stopped
5 Operational
127 Pre-Operat.
250 Failed
255 NoResponse
Subcodes Info
C00347/1 Status node 1 ... 15
C00347/...
C00347/15
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
