15 Parameter reference
15.2 Parameter list
910
Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C00486
C00487
C00488
Parameter | Name:
C00486 | Application units: Text
Data type: VISIBLE_STRING
Index: 24089
d
= 5E19
h
From version 06.00.00
The LS_DisFree_a
SB: Text for the display of the input variables in application unit
Display of internal process factors in application units
Subcodes Lenze setting Info
C00486/1 Application unit 1: Text
C00486/2 Application unit 2: Text
C00486/3 Application unit 3: Text
C00486/4 Application unit 4: Text
 Read access  Write access  CINH  PLC-STOP  No transfer  COM  MOT Character length: 7
Parameter | Name:
C00487 - Application units
Data type: INTEGER_32
Index: 24088
d
= 5E18
h
From version 06.00.00
SB LS_DisFree_a
: Display of the input values in a configurable application unit
Display of internal process factors in application units
Display range (min. value | unit | max. value)
-21474836.47 units 21474836.47
Subcodes Info
C00487/1 Application units 1
C00487/2 Application units 2
C00487/3 Application units 3
C00487/4 Application units 4
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 100
Parameter | Name:
C00488 | L_JogCtrlEdgeDetect
Data type: UNSIGNED_8
Index: 24087
d
= 5E17
h
From version 02.00.00
The L_JogCtrlExtension_1
FB: Signal methodology
• Selection whether the corresponding function is to be activated by edge or level.
Selection list
0 Level
1Edge
Subcodes Lenze setting Info
C00488/1 0: Level InputSens.SlowDown1
• Selection of edge or level for starting slow-down
function 1
C00488/2 0: Level InputSens.Stop1
• Selection of edge or level for stop function 1
