Lenze 8400 - Page 909

Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23 909
15 Parameter reference
15.2 Parameter list
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C00483
C00484
C00485
Parameter | Name:
C00483 | LS_DisFree_p
Data type: INTEGER_32
Index: 24092
d
= 5E1C
h
SB LS_DisFree_p: Display of the input values
Display range (min. value | unit | max. value)
-2147483647 Incr. 2147483647
Subcodes Info
C00483/1 Input values dnDis1_p ... dnDis8_p
C00483/...
C00483/8
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C00484 | Application units: Offset
Data type: INTEGER_16
Index: 24091
d
= 5E1B
h
From version 06.00.00
The LS_DisFree_a
SB: Offset for display of the input variables in application unit
Display of internal process factors in application units
Setting range (min. value | unit | max. value)
-199.99 % 199.99
Subcodes Lenze setting Info
C00484/1 0.00 % Application unit 1: Offset
C00484/2 0.00 % Application unit 2: Offset
C00484/3 0.00 % Application unit 3: Offset
C00484/4 0.00 % Application unit 4: Offset
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 100
Parameter | Name:
C00485 | Application units: Display factor
Data type: INTEGER_32
Index: 24090
d
= 5E1A
h
From version 06.00.00
The LS_DisFree_a
SB: Display factor for display of the input variables in application unit
Display of internal process factors in application units
Setting range (min. value | unit | max. value)
-65536.0000 65536.0000
Subcodes Lenze setting Info
C00485/1 1.0000 Application unit 1: Display factor
C00485/2 1.0000 Application unit 2: Display factor
C00485/3 1.0000 Application unit 3: Display factor
C00485/4 1.0000 Application unit 4: Display factor
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 10000
