15 Parameter reference
15.2 Parameter list
908
Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C00480
C00481
C00482
Parameter | Name:
C00480 | LS_DisFree_b
Data type: UNSIGNED_16
Index: 24095
d
= 5E1F
h
The LS_DisFree_b SB: Display of the input values
Display area (min. hex value | max. hex value)
0x0000 0xFFFF
Value is bit-coded: Info
Bit 0 bDis1 Signal level input bDis1 ... bDis16
... ...
Bit 15 bDis16
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT
Parameter | Name:
C00481 | LS_DisFree
Data type: UNSIGNED_16
Index: 24094
d
= 5E1E
h
The LS_DisFree SB: Display of the input values
Display area (min. hex value | max. hex value)
0x0000 0xFFFF
Value is bit-coded:
Bit 0 Active
... ...
Bit 15 Active
Subcodes Info
C00481/1 Input values wDis1 ... wDis8
C00481/...
C00481/8
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT
Parameter | Name:
C00482 | LS_DisFree_a
Data type: INTEGER_16
Index: 24093
d
= 5E1D
h
The LS_DisFree_a SB: Display of the input values
Display range (min. value | unit | max. value)
-199.99 % 199.99
Subcodes Info
C00482/1 Input values nDis1_a ... nDis8_a
C00482/...
C00482/8
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 100
