15 Parameter reference
15.2 Parameter list
938
Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C00621/86 0: Not connected LP_MciOut: bOut2_B9
MCI output: Data word 2 - bit 9
C00621/87 0: Not connected LP_MciOut
: bOut2_B10
MCI output: Data word 2 - bit 10
C00621/88 0: Not connected LP_MciOut
: bOut2_B11
MCI output: Data word 2 - bit 11
C00621/89 0: Not connected LP_MciOut
: bOut2_B12
MCI output: Data word 2 - bit 12
C00621/90 0: Not connected LP_MciOut
: bOut2_B13
MCI output: Data word 2 - bit 13
C00621/91 0: Not connected LP_MciOut
: bOut2_B14
MCI output: Data word 2 - bit 14
C00621/92 0: Not connected LP_MciOut
: bOut2_B15
MCI output: Data word 2 - bit 15
C00621/93 0: Not connected LS_SetError_1
: bSetError1
Input for tripping "US01: User error 1"
C00621/94 0: Not connected LS_SetError_1
: bSetError2
Input for tripping "US02: User error 2"
C00621/95 0: Not connected LS_SetError_1
: bSetError3
Input for tripping "US03: User error 3"
C00621/96 0: Not connected LS_SetError_1
: bSetError4
Input for tripping "US04: User error 4"
C00621/97 0: Not connected LS_DigitalInput
: bCountIn6_Reset
Digital input 6: Reset counter
C00621/98 0: Not connected LS_DigitalInput
: bCountIn6_LoadStartValue
Digital input 6: Load counter starting value
C00621/99 0: Not connected LS_DigitalOutput
: bOut2
Digital output 2: Input signal
C00621/100 0: Not connected LS_DigitalOutput
: bOut3
Digital output 3: Input signal
C00621/101 0: Not connected LS_DigitalOutput
: bOut HighCurrent
Digital output (HC) for brake control: Input signal
C00621/102 0: Not connected LS_DisFree_b
: bDis9
Display of digital signal 9
C00621/103 0: Not connected LS_DisFree_b
: bDis10
Display of digital signal 10
C00621/104 0: Not connected LS_DisFree_b
: bDis11
Display of digital signal 11
C00621/105 0: Not connected LS_DisFree_b
: bDis12
Display of digital signal 12
C00621/106 0: Not connected LS_DisFree_b
: bDis13
Display of digital signal 13
C00621/107 0: Not connected LS_DisFree_b
: bDis14
Display of digital signal 14
C00621/108 0: Not connected LS_DisFree_b
: bDis15
Display of digital signal 15
C00621/109 0: Not connected LS_DisFree_b
: bDis16
Display of digital signal 16
C00621/111 0: Not connected LS_ParReadWrite_1
: bExecute
Read/write request 1: Trigger
Parameter | Name:
C00621 | System connection list: Bool
Data type: UNSIGNED_16
Index: 23954
d
= 5D92
h
