Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23 945
15 Parameter reference
15.2 Parameter list
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C00639
C00640
C00643
C00650
Parameter | Name:
C00639 | L_NSet_1: Output additional value
Data type: INTEGER_16
Index: 23936
d
= 5D80
h
The L_NSet_1 FB: Additional speed setpoint is displayed after being processed by the ramp generator
Display range (min. value | unit | max. value)
-199.99 % 199.99
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 100
Parameter | Name:
C00640 | L_NSet_1: nNOut_a
Data type: INTEGER_16
Index: 23935
d
= 5D7F
h
The L_NSet_1 FB: Display of the generated main speed setpoint at the output nNOut_a
Display range (min. value | unit | max. value)
-199.99 % 199.99
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 100
Parameter | Name:
C00643 | Resp. to PLI monitoring
Data type: UNSIGNED_8
Index: 23932
d
= 5D7C
h
From version 11.00.00
Pole position identification without motion
Selection list
0 No Reaction
1Fault
3 TroubleQuickStop
4 WarningLocked
5 Warning
6 Information
Subcodes Lenze setting Info
C00643/1 1: Fault Response to PLI monitoring
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C00650 | L_Arithmetik 3-5: Function
Data type: UNSIGNED_8
Index: 23925
d
= 5D75
h
Selection of the internal arithmetics
Selection list
0 nOut_a = nIn1_a
1 nOut_a = nIn1_a + nIn2_a
2 nOut_a = nIn1_a - nIn2_a
3 nOut_a = (nIn1_a * nIn2_a) / 100%
4 nOut_a = (nIn1_a * 1%) / |nIn2_a|
5 nOut_a = (nIn1_a * 100%) / (100% -
nIn2_a)
