Lenze 8400 - Page 982

15 Parameter reference
15.2 Parameter list
982
Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C00831
C00830/81 L_MPot_1
: nIn_a
C00830/82 L_MulDiv_1
: nIn_a
C00830/83 LS_DataAccess: wIn1
(Lenze-internal)
C00830/84 LS_DataAccess: wIn2
(Lenze-internal)
C00830/85 LS_DataAccess: wIn3
(Lenze-internal)
C00830/86 LS_DataAccess: wIn4
(Lenze-internal)
C00830/87 L_PT1_1
: nIn_a
C00830/88 MCTRL
: nSpeedHighLimit_a
C00830/89 L_PCTRL_1
: nNSet_a
C00830/90 L_PCTRL_1
: nISet_a
C00830/91 L_Interpolator_1
: nPhdIn_v
C00830/92 L_Interpolator_1
: nNIn_a
C00830/96 MCTRL
: nInertiaAdapt_a
C00830/97 MCTRL
: nSpeedSetValueInertia_a
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 100
Parameter | Name:
C00830 | 16-bit inputs [%]
Data type: INTEGER_16
Index: 23745
d
= 5CC1
h
Parameter | Name:
C00831 | 16-bit inputs
Data type: UNSIGNED_16
Index: 23744
d
= 5CC0
h
Decimal/hexadecimal/bit coded display of 16 bit input values of various blocks
• Non-listed subcodes are "reserved".
Display area (min. hex value | max. hex value)
0x0000 0xFFFF
Value is bit-coded:
Bit 0 Active
... ...
Bit 15 Active
Subcodes Info
C00831/1 L_Absolut_1
: nIn_a
C00831/2 L_AddSub_1
: nIn1_a
C00831/3 L_AddSub_1
: nIn2_a
C00831/4 L_AddSub_1
: nIn3_a
C00831/5 L_OffsetGain_1
: nIn_a
C00831/6 L_OffsetGain_1
: nOffset_a
C00831/7 L_OffsetGain_1
: nGain_a
C00831/8 L_Negation_1
: nIn_a
C00831/9 L_GainOffset_1
: nIn_a
C00831/10 L_GainOffset_1
: nGain_a
C00831/11 L_GainOffset_1
: nOffset_a
C00831/12 L_Arithmetik_1
: nIn1_a
C00831/13 L_Arithmetik_1
: nIn2_a
