Lenze 8400 - Page 984

15 Parameter reference
15.2 Parameter list
984
Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C00832
C00831/63 L_PCTRL_1
: nSet_a
C00831/64 L_PCTRL_1
: nInfluence_a
C00831/65 MCK: nSpeedCtrlI_a
C00831/66 MCK: nPWMAngleOffset_a
C00831/68 MCK: nMBrakeAddValue_a
C00831/69 MCK: nTorqueSetValue_a
C00831/70 MCK: nTorqueLimitAdapt_a
C00831/71 MCK: nSRampOverride_a
C00831/72 MCK: nSpeedSetValue_a
C00831/73 MCK: wMotionCtrl2
C00831/74 MCK: wMotionCtrl1
C00831/75 MCK: nSpeedOverride_a
C00831/76 MCK: nAccOverride_a
C00831/77 MCK: nSpeedAdd_v
C00831/78 MCK: wAuxCtrl
C00831/79 MCK: wSMCtrl
C00831/80 L_OffsetGainP_3
: nIn_a
C00831/81 L_MPot_1
: nIn_a
C00831/82 L_MulDiv_1
: nIn_a
C00831/83 LS_DataAccess: wIn1
(Lenze-internal)
C00831/84 LS_DataAccess: wIn2
(Lenze-internal)
C00831/85 LS_DataAccess: wIn3
(Lenze-internal)
C00831/86 LS_DataAccess: wIn4
(Lenze-internal)
C00831/87 L_PT1_1
: nIn_a
C00831/88 MCTRL: nSpeedHighLimit_a
C00831/89 L_PCTRL_1
: nNSet_a
C00831/90 L_PCTRL_1
: nISet_a
C00831/91 L_Interpolator_1: nPhdIn_v
C00831/92 L_Interpolator_1
: nNIn
C00831/96 MCTRL
: nInertiaAdapt_a
C00831/97 MCTRL
: nSpeedSetValueInertia_a
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT
Parameter | Name:
C00831 | 16-bit inputs
Data type: UNSIGNED_16
Index: 23744
d
= 5CC0
h
Parameter | Name:
C00832 | 16-bit inputs [incr./ms]
Data type: INTEGER_16
Index: 23743
d
= 5CBF
h
Display of 16-bit input values of different blocks in [rpm]
• Non-listed subcodes are "reserved".
Display range (min. value | unit | max. value)
-32767 Incr./ms 32767
Subcodes Info
