Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23 987
15 Parameter reference
15.2 Parameter list
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C00833
C00832/92 L_Interpolator_1
: nNIn_a
C00832/96 MCTRL
: nInertiaAdapt_a
C00832/97 MCTRL
: nSpeedSetValueInertia_a
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C00832 | 16-bit inputs [incr./ms]
Data type: INTEGER_16
Index: 23743
d
= 5CBF
h
Parameter | Name:
C00833 | Binary inputs
Data type: UNSIGNED_8
Index: 23742
d
= 5CBE
h
Display of the signal status of the binary inputs of different blocks
• Non-listed subcodes are "reserved".
Selection list
0 False
1 True
Subcodes Info
C00833/1 L_And_1
: bIn1
C00833/2 L_And_1
: bIn2
C00833/3 L_And_1
: bIn3
C00833/4 L_DFlipFlop_1
: bD
C00833/5 L_DFlipFlop_1
: bClk
C00833/6 L_DFlipFlop_1
: bClr
C00833/7 L_Not_1
: bIn
C00833/8 L_Or_1
: bIn1
C00833/9 L_Or_1
: bIn2
C00833/10 L_Or_1
: bIn3
C00833/11 L_RLQ_1
: bCw
C00833/12 L_RLQ_1: bCcw
C00833/13 L_AnalogSwitch_1
: bSet
C00833/14 L_NSet_1: bRfgStop
C00833/15 L_NSet_1
: bRfg0
C00833/16 L_NSet_1
: bNSetInv
C00833/17 L_NSet_1: bJog1
C00833/18 L_NSet_1
: bJog2
C00833/19 L_NSet_1
: bJog4
C00833/20 L_NSet_1
: bJog8
C00833/21 L_NSet_1
: bTi1
C00833/22 L_NSet_1
: bTi2
C00833/23 L_NSet_1
: bTi4
C00833/24 L_NSet_1
: bTi8
C00833/25 L_NSet_1
: bLoad
C00833/26 L_NSet_1
: bExternalCINH
C00833/27 MCTRL
: bPosCtrlOn
C00833/28 MCTRL
: bSpeedInterpolatorOn
C00833/29 MCTRL
: bTorqueInterpolatorOn
C00833/30 MCTRL
: bTorquemodeOn
