Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23 995
15 Parameter reference
15.2 Parameter list
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C00836/25 L_OffsetGain_3: nGain_a
C00836/26 L_PT1_2
: nIn_a
C00836/27 L_PT1_3
: nIn_a
C00836/28 L_PhaseIntK_2
: nIn_v
C00836/29 L_SampleHold_1
: nIn_a
C00836/30 L_SampleHold_2
: nIn_a
C00836/31 L_Mux_1
: wInSelect
C00836/32 L_GainOffset_3
: nIn_a
C00836/33 L_GainOffset_3
: nGain_a
C00836/34 L_GainOffset_3
: nOffset_a
C00836/35 L_MulDiv_2
: nIn_a
C00836/36 L_DT1_1
: nIn_a
C00836/37 L_Counter_1
: wLdVal
C00836/38 L_Counter_1
: wCmpVal
C00836/39 L_GainOffsetP_1
: nIn_a
C00836/40 L_GainOffsetP_2
: nIn_a
C00836/41 L_GainOffsetP_3
: nIn_a
C00836/42 L_Limit_1
: nIn_a
C00836/43 L_Limit_2
: nIn_a
C00836/44 L_MckCtrlInterface_1
: wOperationMode
C00836/45 L_MckCtrlInterface_1
: wPosMode
C00836/46 L_MckCtrlInterface_1
: wProfileNo
C00836/47 L_MckCtrlInterface_1
: wInMckPosCtrl_1
C00836/48 L_MckCtrlInterface_1
: wInMckPosCtrl_2
C00836/49 L_MckStateInterface_1
: wInMckPosState_1
C00836/50 L_MckStateInterface_1: wInMckPosState_2
C00836/51 L_PosiShaftCtrlInterface_1
: wInPosiShaftCtrl_1
C00836/52 L_PosiShaftCtrlInterface_1: wInPosiShaftCtrl_2
C00836/53 L_PosiShaftCtrlInterface_1
: wInPosiShaftCtrl_3
C00836/54 L_PosiShaftCtrlInterface_1
: wInPosiShaftCtrl_4
C00836/55 L_ConvWordToBits_1: wInput
C00836/56 L_ConvWordToBits_2
: wInput
C00836/57 L_ConvWordToBits_3
: wInput
C00836/58 L_ConvWordsToDInt_1
: wInLWord
C00836/59 L_ConvWordsToDInt_1
: wInHWord
C00836/60 L_ConvWordsToDInt_2
: wInLWord
C00836/61 L_ConvWordsToDInt_2
: wInHWord
C00836/62 L_ConvWordsToDInt_3
: wInLWord
C00836/63 L_ConvWordsToDInt_3
: wInHWord
C00836/64 L_ConvUnitsToIncr_1
: wInLWord
C00836/65 L_ConvUnitsToIncr_1
: wInHWord
C00836/66 L_ConvUnitsToIncr_2
: wInLWord
C00836/67 L_ConvUnitsToIncr_2
: wInHWord
C00836/68 L_ConvUnitsToIncr_3
: wInLWord
Parameter | Name:
C00836 | 16-bit inputs (Set2)
Data type: UNSIGNED_16
Index: 23739
d
= 5CBB
h
