15 Parameter reference
15.2 Parameter list
994
Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C00836
C00835/135 L_ConvPP_2
: nNum
C00835/136 L_ConvPP_2
: wDenom
C00835/137 L_ConvPP_3
: nNum
C00835/138 L_ConvPP_3
: wDenom
C00835/139 L_Curve_2
: nIn_a
C00835/140 L_Curve_3
: nIn_a
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 100
Parameter | Name:
C00835 | 16-bit inputs [%] (Set2)
Data type: INTEGER_16
Index: 23740
d
= 5CBC
h
Parameter | Name:
C00836 | 16-bit inputs (Set2)
Data type: UNSIGNED_16
Index: 23739
d
= 5CBB
h
Decimal/hexadecimal/bit coded display of 16 bit input values of various blocks
• Non-listed subcodes are "reserved".
Display area (min. hex value | max. hex value)
0x0000 0xFFFF
Value is bit-coded:
Bit 0 Active
... ...
Bit 15 Active
Subcodes Info
C00836/1 L_Absolut_2
: nIn_a
C00836/2 L_AnalogSwitch_4
: nIn1_a
C00836/3 L_AnalogSwitch_4
: nIn2_a
C00836/4 L_AnalogSwitch_5
: nIn1_a
C00836/5 L_AnalogSwitch_5
: nIn2_a
C00836/6 L_Compare_4: nIn1_a
C00836/7 L_Compare_4
: nIn2_a
C00836/8 L_Compare_5: nIn1_a
C00836/9 L_Compare_5
: nIn2_a
C00836/10 L_Arithmetik_3
: nIn1_a
C00836/11 L_Arithmetik_3: nIn2_a
C00836/12 L_Arithmetik_4
: nIn1_a
C00836/13 L_Arithmetik_4
: nIn2_a
C00836/14 L_Arithmetik_5
: nIn1_a
C00836/15 L_Arithmetik_5
: nIn2_a
C00836/16 L_Counter_2
: wLdVal
C00836/17 L_Counter_2
: wCmpVal
C00836/18 L_Counter_3
: wLdVal
C00836/19 L_Counter_3
: wCmpVal
C00836/20 L_PhaseIntK_1
: nIn_v
C00836/21 L_Negation_2
: nIn_a
C00836/22 L_NLim_2
: nIn_a
C00836/23 L_OffsetGain_3
: nIn_a
C00836/24 L_OffsetGain_3
: nOffset_a
