Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23 997
15 Parameter reference
15.2 Parameter list
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C00837
C00836/113 L_DFSET_1
: wGainNum
C00836/114 L_DFSET_1
: nSet_v
C00836/115 L_DFSET_1
: wGainDenom
C00836/116 L_DFSET_1
: wGearDenom
C00836/117 L_DFSET_1
: nPositionTrimming
C00836/118 L_DFSET_1
: nNAct_v
C00836/119 L_DFRFG_1
: nIn_v
C00836/120 L_GearComp_1
: nTorque_a
C00836/121 L_ConvAP_1
: nIn_a
C00836/122 L_ConvAP_2
: nIn_a
C00836/123 L_ConvAP_3
: nIn_a
C00836/124 L_ConvX_1
: nIn_a
C00836/125 L_ConvX_1
: nNum
C00836/126 L_ConvX_1
: wDenom
C00836/127 L_ConvX_2
: nIn_a
C00836/128 L_ConvX_2
: nNum
C00836/129 L_ConvX_2
: wDenom
C00836/130 L_ConvX_3
: nIn_a
C00836/131 L_ConvX_3
: nNum
C00836/132 L_ConvX_3
: wDenom
C00836/133 L_ConvPP_1
: nNum
C00836/134 L_ConvPP_1
: wDenom
C00836/135 L_ConvPP_2
: nNum
C00836/136 L_ConvPP_2
: wDenom
C00836/137 L_ConvPP_3
: nNum
C00836/138 L_ConvPP_3: wDenom
C00836/139 L_Curve_2
: nIn_a
C00836/140 L_Curve_3: nIn_a
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT
Parameter | Name:
C00836 | 16-bit inputs (Set2)
Data type: UNSIGNED_16
Index: 23739
d
= 5CBB
h
Parameter | Name:
C00837 | 16-bit inputs [incr./ms] (Set2)
Data type: INTEGER_16
Index: 23738
d
= 5CBA
h
Display of 16-bit input values of different blocks in [rpm]
• Non-listed subcodes are "reserved".
Display range (min. value | unit | max. value)
-32767 Incr./ms 32767
Subcodes Info
C00837/1 L_Absolut_2
: nIn_a
C00837/2 L_AnalogSwitch_4
: nIn1_a
C00837/3 L_AnalogSwitch_4
: nIn2_a
C00837/4 L_AnalogSwitch_5
: nIn1_a
C00837/5 L_AnalogSwitch_5
: nIn2_a
C00837/6 L_Compare_4
: nIn1_a
