Lexmark MX610 - Imaging Unit Low Service Check; Toner Cartridge Low Service Check

Action Yes No
Step 3
a Print the Menu settings page:
Settings > Reports > Menu Settings Page
b POR into the Configuration menu and reset the printer’s settings to
factory default:
Configuration Menu > Factory Defaults > Restore Base
c Remove the memory card.
d Restart the printer.
Does the error remain?
Replace the controller
board. See “Controller
board removal” on
page 257.
Replace the memory
card.
Imaging unit low service check
Action Yes No
Step 1
Replace the imaging unit.
Does the problem remain?
Go to step 2. The problem is solved.
Step 2
a Make sure the imaging unit smart chip contact cable is properly
connected to the controller board.
b Make sure the contacts are free of debris.
Does the problem remain?
Go to step 3. The problem is solved.
Step 3
Check the contacts for damaged pins.
Are they free of damage?
Contact the next level
of support.
Replace the printer.
Toner cartridge low service check
Action Yes No
Step 1
Replace the toner cartridge.
Does the problem remain?
Go to step 2. The problem is solved.
Step 2
a Make sure the toner cartridge smart chip contact cable JARW1 is
properly connected to the controller board.
b Make sure the contacts are free of debris.
Does the problem remain?
Go to step 3. The problem is solved.
7016
Diagnostic information
116
