PART EVERY 90K EVERY 200K NOTES
ADF ASSEMBLY
ADF separator roll Replace
ADF restraint pad Replace if dirty, or if the ADF is shingle feeding.
Scheduled maintenance
The control panel displays an 80.xy error when it reaches 200K page counts. It is necessary to install the appropriate
maintenance kit to maintain the print quality and reliability of the printer. Reset the maintenance counter after replacing
the maintenance kit.
Maintenance kits
Part number and kit Contents
40X9147—Maintenance Kit (100 V)
• Fuser (100V)
• Redrive assembly
• ACM tires/hubs
• Transfer roll
• Tray separator bracket
• MPF pick roll and separator pad
40X9137—Maintenance Kit (110 V)
• Fuser (110V)
• Redrive assembly
• ACM tires/hubs
• Transfer roll
• Tray separator bracket
• MPF pick roll and separator pad
40X9138—Maintenance Kit (220 V)
• Fuser (220V)
• Redrive assembly
• ACM tires/hubs
• Transfer roll
• Tray separator bracket
• MPF pick roll and separator pad
When performing the 200K scheduled maintenance procedure, the following areas should be cleaned of media dust
and toner contamination:
• Media trays
• Imaging unit area
• Transfer roll area
• Duplex area
• Standard bin
7016
Maintenance
410
