Memory access door removal
1 Open the memory access door.
2 Gently release the latches (A) securing the access door to the right cover.
3 Slide the access door to release the hinges, then remove it from the right cover.
Tray present sensor removal
1 Remove the right cover. See “Right cover removal” on page 252.
2 Disconnect the cable (A) from the tray present sensor.
7016
Repair information
255
