General information
The Lexmark
TM
MX610 and MX611 (7016‑6xx) are network‑capable, multifunction laser printers that print monochrome
print jobs. All information in this service manual pertains to all models unless explicitly noted.
The printers are available in the following models:
Model Configurations Machine type / model
MX610de Mono laser MFP, Networking, Duplex print, e‑task 7‑inch
color touch screen
7016-630
MX611de Mono laser MFP, Networking/Fax, Duplex print/scan,
e‑Task 7‑inch color touch screen
7016-670
XM3150 7016-679
MX611dhe Mono laser MFP, Networking/Fax, Duplex print/scan,
e‑Task 7‑inch color touch screen, Hard disk
7016-675
The diagnostic information in this manual leads you to the correct field replaceable unit (FRU) or part. Use the error
code charts, symptom index, and service checks to determine the symptom and then repair the failure. After you
complete the repair, perform tests as needed to verify the repair.
To begin diagnosing a problem, go to “Diagnostic information” on page 37. For information about removing and
reinstalling parts, see “Repair information” on page 217. See “Parts catalog” on page 414 to help identify parts.
Media guidelines
Additional information for printing on specialty media may be found in the Cardstock and Label Guide available at
http://support.lexmark.com.
Paper guidelines
Selecting the correct paper or specialty media reduces printing problems. For the best print quality, try a sample of the
paper or specialty media before buying large quantities.
Paper characteristics
The following paper characteristics affect print quality and reliability. Consider these characteristics when evaluating
new paper stock.
Weight
The standard printer trays can automatically feed paper weights up to 90‑g/m
2
(24‑lb) bond grain long paper. The
optional trays can automatically feed paper weights up to 120‑g/m
2
(32‑lb) bond grain long paper. The multipurpose
feeder can automatically feed paper weights up to 163‑g/m
2
(43‑lb) bond grain long paper. Paper lighter than
60 g/m
2
(16 lb) might not be stiff enough to feed properly, causing jams. For best performance, use 75‑g/m
2
(20‑lb)
bond grain long paper. For paper smaller than 182 x 257 mm (7.2 x 10.1 inches), it is recommended to use 90 g/m
2
(24 lb) or heavier paper.
Note: Two‑sided printing is supported only for 60–90‑g/m
2
(16–24‑lb) bond paper.
7016
General information
27
