FINISHER TESTS
Staple Test
This test verifies the operation of the staple mechanism in the finisher. The printer feeds eight pieces of media to the
finisher and accumulates all eight pieces in the finisher. After the last sheets are accumulated, the pack is stapled.
1 Enter Diagnostics menu, and then select FINISHER TESTS.
2 Select Staple Test.
Staple Test Running... appears while the test is running.
Feed Test
This test verifies that media can be fed from the default source to a finisher bin. Any paper size that is supported can
be used. The printer feeds one blank sheet of media from the default paper source to the finisher bin.
1 Enter Diagnostics menu, and then select FINISHER TESTS.
2 Select Feed Test.
Feed Tests Running... appears while the test is running.
Sensor Test
Use this sensor test to determine that the sensors located inside the finisher are operating correctly.
CAUTION—SHOCK HAZARD: Do not use your hand to toggle these switches. Use a nonconducting object.
To run the Sensor test:
1 Enter Diagnostics menu, and then navigate to FINISHER TESTS.
2 Select the sensor from the options listed:
• Staple Sensors
• Pass and Media
• Cover and Door
• Bin Level
• Compile and Diverter
• Initial Sensors
3 Manually toggle the selected sensor to verify if the values change between Open and Closed. If the values do
not change, then the sensor is malfunctioning.
4 To exit the test, press X.
BASE SENSOR TEST
Use the Base Sensor Test to determine that the sensors located inside the printer are operating correctly.
7016
Service menus
189
