Assembly 9: Staple finisher (right)
Asm-index P/N Units/mach Units/FRU Description Removal procedure
1 40X8144 1 1 Stapler interface cable “Stapler interface cable
removal” on page 374
2 40X7592 1 1 Sensor (stapler access door) “Sensor (stapler access door)
removal” on page 358
3 40X8139 1 1 Stapler door close limit switch with cable “Stapler door close limit
switch removal” on page 360
4 40X8142 1 1 Stapler carriage assembly “Stapler carriage assembly
removal” on page 358
5 40X8130 1 1 Stapler right cover “Stapler right cover removal”
on page 355
6 40X8129 1 1 Stapler cartridge access door “Stapler cartridge access door
removal” on page 353
7 40X8149 1 1 Staple roll holder “Staple roll holder removal”
on page 354
7016
Parts catalog
432
