Lexmark MX610 - Cartridge Gearbox Removal

8 Remove the two screws (A) securing the reverse solenoid.
Cartridge gearbox removal
1 Remove the left cover. See “Left cover removal” on page 239.
2 Remove the four screws (A) securing the cartridge gearbox.
3 Disconnect the cable from the cartridge gearbox.
7016
Repair information
249
