Connector Connects to Pin no. Signal
J30 CCD module 1 FBR_LAMP_ON
2GND
3V24_14V_FB_CDU
4V24_14V_FB_CDU
5GND
6 V24_5V_FB_CDU
7 V24_5V_FB_CDU
8FB_POWER_SAVER
9GND
10 FBR_AFE_SEN
11 FBR_AFE_SCK
12 FBR_AFE_SDIO
13 GND
14 FBR_AFE_SH
15 GND
16 FB_LVDS_RXIN0+
17 FB_LVDS_RXIN0-
18 GND
19 FB_LVDS_RXIN1+
20 FB_LVDS_RXIN1-
21 GND
22 FB_LVDS_RXIN2+
23 FB_LVDS_RXIN2-
24 GND
25 FB_LVDS_RXCLK+
26 FB_LVDS_RXCLK-
27 GND
28 FB_LVDS_MCLK+
29 FB_LVDS_MCLK-
30 GND
7016
