Connector Connects to Pin no. Signal
JLSU1 LSU, video 1 LDEN_C
2SHADE_C
3 VDO_ADJ_C
4GND
5LPOWER_C
6BOOST_C
7GND
8VIDEO-_C
9 VIDEO+_C
10 GND
JMPFP1 Sensor (MPF) 1 +3.3_ENG_SW
2 S_MPF_PP_C
3GND
JMTR1 Main motor 1 HALL_U_C
2 HALL_V_C
3 HALL_W_C
4FG_C
5GND
6+5_MOTFUSE
7V_C1_U
8V_C1_V
9V_C1_W
JOPT1 Options 1 VS24_FUSE_OPT
2J_OPT_TXR
3 J_INPUT_FDT
4J_OPT_RXR
5GND
6 VS24_OPT_5V
JPLEN1 Sensor (flatbed paper length) 1 GND
2LENGTH_FBR
3+5V_LENGTH
7016
Component locations
