Assembly 1: Covers
Asm-index P/N Units/mach Units/FRU Description Removal procedure
1 40X9102 1 1 Output expander N/A
2 40X9099 1 1 Top cover “Top cover removal” on page 324
3 40X9096 1 1 Exit rear door “Rear exit door removal” on page 317
4 40X9084 1 1 Diverter cover “Diverter cover removal” on page 323
5 40X9087 1 1 Rear cover “Rear cover removal” on page 318
6 40X9090 1 1 Right cover “Right cover removal” on page 252
7 40X9100 1 1 Memory access door (MFP) “Memory access door removal” on page
255
8 40X8086 1 1 550‑sheet tray N/A
9 40X9148 1 1 Cartridge plunger “Cartridge plunger removal” on page 268
10 40X9101 1 1 Name plate cover “Name plate cover removal” on page 270
11 40X9095 1 1 Front bin cover “Front bin cover removal” on page 272
12 40X9131 1 1 MPF tray cover “MPF tray removal” on page 286
13 40X9068 1 1 Front access cover (MPF) “Front access cover removal” on page 291
14 40X9086 1 1 Left cover “Left cover removal” on page 239
15 40X9126 1 1 Bin full sensor cable “Bin full sensor cable removal” on page
327
16 40X9092 1 2 Bin full sensor “Bin full sensor/lens removal” on page 325
17 40X9127 1 1 IR sensor lens “Bin full sensor/lens removal” on page 325
7016
Parts catalog
416
