Assembly 2: Imaging
Asm-index P/N Units/mach Units/FRU Description Removal procedure
1 40X9108 1 1 ADF separator roller “ADF separator roll removal ” on page 330
2 40X9054 1 1 ADF input tray “ADF input tray removal” on page 333
3 40X9093 1 1 ADF assembly “ADF unit removal” on page 333
4 40X9110 1 1 Restraint pad “Restraint pad removal” on page 345
5 40X5804 1 1 Flatbed cushion (legal) “Flatbed cushion removal ” on page 331
6 40X7546 1 1 ADF right hinge “ADF hinge removal” on page 342
7 40X9094 1 1 Flatbed “Flatbed assembly removal” on page 343
8 40X9051 1 1 MPF USB cable “USB cable removal” on page 340
9 40X9053 1 1 USB cable bracket “USB cable bracket removal” on page 279
10 40X9097 1 1 Scanner front cover “Scanner front cover removal” on page 332
11 40X9088 1 1 Cave light lens “Cave light lens removal” on page 280
12 40X9080 1 1 Speaker cable “Speaker cable removal” on page 343
13 40X9129 1 1 ADF left hinge “ADF hinge removal” on page 342
14 40X9050 1 1 MPF wireless cable “USB wireless cable removal” on page 341
15 40X9079 1 1 Speaker “Speaker removal” on page 279
16 40X8736 1 1 ADF pick roll N/A
17 40X9142 1 1 ADF top cover (legal) “ADF top cover assembly removal” on page 338
18 40X9117 1 1 High end ADF cable “ADF cable removal” on page 339
7016
Parts catalog
418
