Assembly 5: Electronics 2
Asm-index P/N Units/mach Units/FRU Description Removal procedure
1 40X8048 1 1 Front door sensor “Front door sensor removal” on
page 293
2 40X8266 1 1 Cartridge smart chip contact “Toner cartridge smart chip contact
removal” on page 261
3 40X8046 1 1 Toner density sensor “Toner density sensor removal” on
page 305
4 40X7797 1 1 Power supply, 100 V/110 V “Power supply removal” on page 298
4 40X7798 1 1 Power supply, 220 V “Power supply removal” on page 298
5 40X8045 1 1 Trailing edge sensor “Trailing edge sensor removal” on
page 306
6 40X8043 1 1 Duplex sensor and input sensor “Duplex sensor and input sensor
removal” on page 300
7 40X8800 1 1 Media present sensor flag “Media present sensor flag removal” on
page 307
8 40X7592 1 1 Media present sensor “Media present sensor removal” on
page 303
9 40X8044 1 1 Index sensor “Index sensor removal” on page 303
7016
Parts catalog
424
